For HZS150 concrete batching plant, it adopts twin shafts concrete mixing machine with the uniform mixing and high output of production. Well, the admixtures are widely mixed by shafts to reach the best proportional ratio. With the advanced technology and information around the world, the concrete batching plant has been used widely in construction sites and building places to promote the development of city.


HZS150 concrete batch plant main specifications
1. Water is flow-metering, simple and practical, highly accurate dosing.
2. Aggregate batching system adopts PLD4800 concrete batcher which offers efficient and accurate measurement;
3. Powder lot is electronic measured, highly accurate dosing;
4. Mixing and aggregate lifting system adopt JS3000 double-shaft compulsory concrete mixer which offers high quality and efficient mixing;
5. Adopt combined structure and modular unit, convenient to install and remove;
Model |
HZS150 |
Specification |
Unit |
Value |
Productivity |
m3/h |
150 |
Capacity of Mixer |
m3 |
3 |
Mix Power |
kw |
110 |
Discharge Height |
m |
3.8 |
Aggregate Bin |
Quantity |
4 |
Aggregate Bin Capacity |
m3 |
4.8 |
Max. Weighing Value of Aggregate |
kg |
1800 |
Max. Weighing Value of Cement |
kg |
800 |
Max. Weighing Value of Water |
kg |
800 |
Max. Weighing Value of Additive |
kg |
50 |
Aggregate Measuring Accuracy |
% |
±2% |
Water Measuring Accuracy |
% |
±1% |
Cement Measuring Accuracy |
% |
±1% |
Additive Measuring Accuracy |
% |
±1% |
Cement Silo |
_ |
Optional |
Cement Screw Conveyor |
_ |
Optional |
Cement Silo Capacity |
_ |
Optional |
Control Mode |
_ |
Auto/Semi Control |
|
