HZS180 Concrete Batching Plant (180m3/h)

HZS180 Concrete Batching Plant (180m3/h)



FOB Reference Price:Get Latest Price
US $45,000-75,000/ Set | 1 Set/Sets (Min. Order)
Type: HM-303
Condition: New
Port:Any port in China

 HZS180F8 Batching Plant makes the maximum productivity to 180 cubic meter per hour. The 180 cubic meter batching plant adopts a modular structure that can be assembled and disassembled rapidly using common hardware. This makes it convenient to move.

HZS180 Concrete Batching Plant (180m3/h)HZS180 Concrete Batching Plant (180m3/h)


Model HZS180
Specification Unit Value
Productivity m3/h 180
Capacity of Mixer m3 3
Mix Power kw 110
Discharge Height m 3.8
Aggregate Bin Quantity 4
Aggregate Bin Capacity m3 4.8
Max. Weighing Value of Aggregate kg 1800
Max. Weighing Value of Cement kg 800
Max. Weighing Value of Water kg 800
Max. Weighing Value of Additive kg 50
Aggregate Measuring Accuracy % ±2%
Water Measuring Accuracy % ±1%
Cement Measuring Accuracy % ±1%
Additive Measuring Accuracy % ±1%
Cement Silo _ Optional
Cement Screw Conveyor _ Optional
Cement Silo Capacity _ Optional
Control Mode _ Auto/Semi Control
