60m3/h portable concrete plant (YHZS60 modular mobile concrete mixing plant) is special construction concrete equipment designed by our company as module. It is applied for airport way, wharf, road, bridge and so on, It can also be used for the large and emergency repair construction operation. It can be installed quickly on site. This mixing plant is consisted by mixer, batching system, feeding system, weighing system, cement silo, screw conveyor and all the necessary equipment, and they are designed as module .So we can deliver YHZS series portable concrete plant easily by container, and install quickly on site and get it to run without debugging. This equipment has the characteristic of high automatic, well mixing, high productivity, high flexibility, convenient operation, and good stability.

|
Specification
|
Unit
|
Value
|
|
theoretical productivity
|
m3/h
|
60
|
|
weighing scale
|
concrete
|
kg
|
3000
|
|
cement
|
kg
|
720
|
|
water
|
kg
|
360
|
|
liquid addictive
|
kg
|
36
|
|
overall power
|
KW
|
about 85
(optional parts not included)
|
|
power source
|
V/ HZ
|
380/50
|
|
discharging height
|
m
|
3.8
|
|
overall weight
|
t
|
24 (optional parts not included)
|
|
trail speed
|
km/h
|
≤40
|
|
specification
(LxWxH)
|
during work
|
m
|
17.7x3.6x8.2
|
|
during transportation
|
m
|
18.3x2.4x4.35
|
|
