75m3/h portable concrete plant (YHZS75 hauling mobile concrete mixing plant) with running system is special construction concrete equipment designed independently by our company. It can be installed quickly on site. This portable concrete plant integrate mixer, batching system, running system, feeding system, weighing system, cement silo, screw conveyor and all the necessary equipment into together, installing on a transport chassis. We can deliver YHZSA series portable concrete plant to construction site in the hauling situation, then install quickly on site and get it to run without debugging. This equipment has the characteristic of high automatic, well mixing, high productivity, high flexibility, convenient operation, and good stability. By absorbing new technologies from overseas and domestic, the portable concrete plant has such characteristics as accurate weighing, homogeneous and efficient mixing, fast and clean delivery, convenient to move and operate, safe trailing, etc.
|
Specification
|
Unit
|
Value
|
|
theoretical productivity
|
m3/h
|
75
|
|
weighing scale
|
concrete
|
kg
|
3750
|
|
cement
|
kg
|
900
|
|
water
|
kg
|
450
|
|
liquid addictive
|
kg
|
45
|
|
overall power
|
KW
|
about 105 (optional parts not included)
|
|
power source
|
V/ HZ
|
380/50
|
|
discharging height
|
m
|
3.8
|
|
overall weight
|
t
|
27 (optional parts not included)
|
|
trail speed
|
km/h
|
≤40
|
|
specification
(LxWxH)
|
during work
|
m
|
18.1x3.6x8.2m
|
|
during transportation
|
m
|
18.6x2.4x4.35m
|
|
